ZNC Series
XYZ axes travel: 300x250x150 mm (12"x10"x6") inch
U Axis travel: 200mm (8")inch
Work table size：600x300mm (24"x12") inch
Max. work piece：800x450x280 mm (31"x18"x11") inch
Max. work piece weight：800 kgs
Max. electrode weight：100 kgs
Machine net weight：1000 kgs
Oil level :110~250mm (4"-10") inch
Occupied dimension (LxWxH):
1610x2144x2147 mm (63.3"x84.4"x84.5" )inch
Work table to platen：155-505 mm (6"x20")inch
Filter： 1
Paper filter：2
Capacity：350 Liters
1.The system adopts Windows CE communication controller.
2. Real-time alarm notification, when an alarm occurs, user can immediately identify and address.
3.Three axis adopt 1μm optical scale
4. Highly scalable interface, Can update software and upgrades through USB.
5. Processing conditions have automatic editing, which can generate the best conditions to optimize processing according to the material , area ,processing depth and final current of the single-sided gap.
6. Utilizing a new generation of processing power circuit, customers can adjust electrodes with finer shapes to achieve the best R-angle accuracy.
7. The newly developed microcomputer numerical control super-hard machining circuit can suppress consumption and greatly shorten the processing time, and achieve the best surface roughness.
8. Excellent processing circuit, can process various materials NAK80, P20, SKD11, stainless steel and special materials titanium alloy, etc.
