ZNC Series
XYZ axes travel: 400x300x185 mm (16"x12"x7") inch
U Axis travel: 250 mm (10")inch
Z Axis single travel: 350mm (14")inch
Work table size：650x400 mm (26"x16") inch
Max. work piece：1000x550x360 mm (39"x22"x14") inch
Max. work piece weight：1100 kgs
Max. electrode weight：130 kgs
Machine net weight：1550 kgs
Oil level :110~300mm (4"-12" )inch
Z axis double Occupied dimension (LxWxH):
1556x3112x2264 mm (61.2"x122.5"x89.1") inch
Z axis single Occupied dimension (LxWxH):
1556x3112x2493 mm (61.2"x122.5"x98.1") inch
Work table to platen：
Z axis single travel: 180-530mm (7"x21") inch
UZ axis：180-615 mm (7"x24") inch
Filter： 1
Paper filter：2
Capacity：450 Liters
1.The system adopts Windows CE communication controller.
2. Real-time alarm notification, when an alarm occurs, user can immediately identify and address.
3.Three axis adopt 1μm optical scale
4. Highly scalable interface, Can update software and upgrades through USB.
5. Processing conditions have automatic editing, which can generate the best conditions to optimize processing according to the material , area ,processing depth and final current of the single-sided gap.
6. Utilizing a new generation of processing power circuit, customers can adjust electrodes with finer shapes to achieve the best R-angle accuracy.
7. The newly developed microcomputer numerical control super-hard machining circuit can suppress consumption and greatly shorten the processing time, and achieve the best surface roughness.
8. Excellent processing circuit, can process various materials NAK80, P20, SKD11, stainless steel and special materials titanium alloy, etc.
